BK Precision 8540 - Page 18

Cursor
position
Voltage
Increment
Current
Increment
Resistance Increment
10 V
Range Increment Range Increment
0-3 A 1 A
0.1-10 Ω 1 Ω
10-99 Ω 10 Ω
0-30 A 10 A
100-999 Ω 100 Ω
1000-4000 Ω 1000 Ω
1 V
0-3 A 0.1 A
0.1-10 Ω 0.1 Ω
10-99 Ω 1 Ω
0-30 A 1 A
100-999 Ω 10 Ω
1000-4000 Ω 100 Ω
0.1 V
0-3 A 0.01 A
0.1-10 Ω 0.01 Ω
10-99 Ω 0.1 Ω
0-30 A 0.1 A
100-999 Ω 1 Ω
1000-4000 Ω 10 Ω
0.01 V
0-3 A 0.001 A
0.1-10 Ω 0.001 Ω
10-99 Ω 0.01 Ω
0-30 A 0.01 A
100-999 Ω 0.1 Ω
1000-4000 Ω 1 Ω
A
B
C
D
Knob incremental values
The following table shows the incremental changes in the set value when
the knob is turned corresponding to which “cursor” LED is lit.
