Top-Off Charge voltage is automatically maintained and reduced to a predetermined level while current
is adjusted for a safe, effective battery charge. At the end of Stage 3, the unit will BEEP signaling the completion of the
charging cycle.
The Automatic Float Charge feature is ideal for maintaining a battery. It automatically tops off battery as needed,
keeping it fully charged all the time.
FEATURES
• This unit has three charge rate settings, accessed by the 2/10/30 AMP button:
a) 2 amps: smaller batteries, such as in lawn mowers, snowmobiles, motorcycles, etc.
b) 10 amps: mid-sized batteries, such as in small cars and trucks, and general use vehicles
c) 30 amps: automobiles, light trucks and utility vehicles
• 80 amp engine start
• Automatic Temperature Compensation
• Battery type selection
• Digital diagnostics
• Alternator voltage and battery voltage check
• Digital display shows charge rate, operating mode, fault codes and FUL when charged
• 1-minute engine start
• 3-stage high-frequency switch mode automatic rapid charging
• Spark resistant reverse polarity and short circuit protection for user
• Lightweight, high-efficiency design
• Internal short circuit protection
• Cables and clamps self-stored
• Reverse polarity indication
• Microprocessor control (Digital Smart Control)/High frequency power
• Compensates for low AC from extension cord use
• Equalization function
CCoonnttrroollss aanndd IInnddiiccaattoorrss
FFuunnccttiioonn BBuuttttoonnss ((ffrroomm lleefftt ttoo rriigghhtt))::
BBaatttteerryy TTyyppee ((SStteepp 11))
allows the user to select Wet, Gel or AGM type of battery for efficient and safe charge.
Most automotive batteries are Wet batteries. Refer to the battery manufacturer’s specifications for battery type.
22//1100//3300 AAMMPP ((CChhaarrggee RRaattee SSeelleeccttoorr)) ((SStteepp 22))
allows the user to select the charge rate based on battery
size. This selection and the actual battery charge rate are monitored by the microprocessor. The charger will
stop charging if the rate is too fast or too slow for the battery size or condition.
8800 AAMMPP EEnnggiinnee SSttaarrtt
places the charger in an engine start sequence. This button will not be activated unless the
charger is in the 30 amp charge mode; set the 2/10/30 amp button to 30 amps first to activate this button.
BBaatttteerryy VVoollttaaggee ((AAlltteerrnnaattoorr VVoollttaaggee CChheecckk))
is a quick check that measures the battery voltage. This check
is repeated at various electrical load levels and the tests allow the user to determine if the alternator can keep
up with the loads.
