DO NOT let children come into contact with the tool. Supervision is required when inexperienced operators use this
tool.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal injury, turn unit off and unplug before making any adjustments or
removing/installing attachments or accessories. An accidental start-up can cause injury.
WARNING: Before attempting any of the assembly steps below, ensure product is switched off and disconnected
from the power supply.
ASSEMBLY FOR BLOW MODE Blow Tube Assembly
Fit fan cover 14 as shown in Fig. C until audible click is heard.
Align the upper 9 and lower tubes 10 as shown in Fig. C.
Push the lower tube firmly into the upper tube, until the tubes click into place.
Blow tubes must be assembled to the power head before use.
Never operate without both lower and upper tubes assembled.
In the interest of safety, it is not intended for the tubes to be separated once assembled.
Push the tube assembly onto the power head until it is in the fully locked in position and an audible click is
heard. (Fig. D).
CAUTION: CUT HAZARD. Ensure the tube assembly is securely seated and latched into position.
Use the air concentrator attachment 11 to target air flow to a tighter area. Add the attachment to the assembly
as shown in Fig. E. Push on until hole in tab engages raised post on tube.
