Black & Decker FSM13E1 User Manual

6
ENGLISH
(Original instructions)
7
ENGLISH
(Original instructions)
After use (Fig. E)
u Turn the steam mop 'OFF'. turn the steam operation
button (2) to off and then press the ON/OFF button (1).
u Wait until the steam mop cools down.
u Unplug the steam mop from the electrical wall outlet.
u Empty the water tank.
u remove the cleaning pad (7) and wash it ready for next
use.
u Wrap the power supply cable around the tidy hook (10).
Technical Data
FSM13E1
Voltage V
ac
230
Power W 1300
Tank
Capacity
ml 380
Weight kg 1.8
Troubleshooting
If your appliance seems not to operate properly, follow the
instructions below. If this does not solve the problem, please
contact your local BLACK+DECKER repair agent.
Problem Step Possible solution
The steam mop is not
turning on
1. Check the unit is
plugged in at the wall
socket.
2. Check the unit is
switched on using the
ON/OFF switch (1)
3. Check the fuse in the
plug.
The steam mop is not
producing steam
4. Check the water tank
(4) is full .
NOTE: When rst lled
or after running dry it
can take up to 45
seconds for steam to
be produced.
5. Check the steam
generation button is in
the ON position (2).
6. The steamer is
equipped with a
thermostat and a
thermal cut-out. If for
any reason the steamer
overheats it will switch
off. If this happens turn
off and unplug the
steamer, allow to cool
for 2 to 4 hours and
re-try.
Where can I get
further information/
accessories for my
steam mop
7. Refer to the assembly
chapter of the manual
for correct tting of
parts and
accessories.

Black & Decker FSM13E1 Specifications

General

Type	-
Capacity	0.38 L
Cord length	4 m
Product color	Blue, White
Operating time	11 min
Steam pressure	- bar
On/off switch	Yes
Steam-ready light	No

Weight and Dimensions

Weight	1800 g
