Black & Decker FSMH1321 - Advanced Usage and Troubleshooting; Technical Data and Troubleshooting

13
ENGLISH
(Original instructions)
Always place the steam mop with the handle (8) supported in
the upright position when stationary and make sure the steam
mop is turned off when not in use.
Carpet refreshing
u Placeacleaningpad(13)ontheoorwiththe'loop'side
facing up.
u lightly press the steam mop down onto the cleaning pad.
u Placethecarpetglider(12d)ontheoor.
u Lightly press the steam mop down onto the carpet glider
until it clicks into place.
u Connect the steam mop to the mains.
u PresstheON/OFFbutton(1).Ittakesapproximately15
seconds for the steam mop to heat up.
u Turn the Autoselect
TM
dial (2) to the Wood/Laminate
setting.
u Push and pull the steam mop slowly across the carpet to
thoroughly refresh each section.
u Whenyouhavenishedusingthesteammop,returnthe
handle(8)totheuprightpositionandturntheunitOFF.
Waituntilthesteammopcoolsdown(approximatelyve
minutes).
After use
u Turn the Autoselect
TM
dial(2)totheOFFposition.
u Wait until the steam mop cools down.
u Unplug the steam mop from the electrical wall outlet.
u Empty the water tank.
u remove the cleaning pad (13) and wash it ready for next
use (take care to follow the wash care instructions printed
on the cleaning pad).
u Wrap the supply cable around the cable tidy hooks (7 and
9).
u There is a hanging bracket (15) built into the hand grip (6)
which allows your steam mop to be hung from a suitable
hook on the wall. Always ensure that your wall hook is
capable of supporting the weight of the steam mop safely.
u The handle also includes a rubber stopper which allows
your steam mop to be rested safely against a vertical
surface.
Hand held steam cleaning
Warning! Unit will not produce steam unless it is connected to
themainbody(11)orthesteamhose(16)istted.
Warning!Onlyuseinahorizontalposition.
u Attach the required accessory.
u Connect the hand held steam cleaner to the mains.
u PresstheON/OFFbutton(1).Ittakesapproximately15
seconds for the steam mop to heat up.
u Turn the Autoselect
TM
dial (2) until the required setting is
reached. After a few seconds steam will start to come out
of the steam head.
Note!Whenrstlledorafterrunningdry,itcantakeupto45
seconds for steam to be produced.
u Whenyouhavenishedusingthehandheldsteam
cleaner turn the Autoselect
TM
dial(2)totheOFFposition.
TurntheunitOFFbypressingtheON/OFFbutton(1)and
disconnect from the mains supply. Wait until the unit cools
downbeforestoring(approximatelyveminutes).
Accessories
The performance of your appliance depends on the accessory
used. BLACK+DECKER accessories are engineered to high
quality standards and designed to enhance the performance
of your appliance. By using these accessories you will get the
very best from your equipment.
Technical Data
Voltage Power Tank
Capacity
Heat-up
time
Cable length Weight
V
ac
W ml secs m kg
FSMH1321 230 1600 500 ≤15 6 2.7
BHSM168D 230 1600 500 ≤15 6 2.8
BHSM168U 230 1600 500 ≤15 6 2.8
BHSM166DSM 230 1600 500 ≤15 6 2.8
BHSM1615DSM 230 1600 500 ≤15 7 2.9
BHSM1615DAM 230 1600 500 ≤15 7 2.9
BHSM1615DSG 230 1600 500 ≤15 8 2.9
BHSM168DSM 230 1600 500 ≤15 8 2.9
BHSM169DSM 230 1600 500 ≤15 8 2.9
BHSM1610DSM 230 1600 500 ≤15 8 2.9
Troubleshooting
If your appliance seems not to operate properly, follow the
instructions below. If this does not solve the problem, please
contact your local BLACK+DECKER repair agent.
Problem Step Possible solution
The steam mop is not
turning on
1. Check the unit is plugged in at the wall
socket.
2. Check the unit is switched on using the
ON/OFFswitch(1)
3. Check the fuse in the plug.
The steam mop is not
producing steam
4. The steam mop will only produce steam if
the hand held steam cleaner (5) is
correctly docked into the main body (11)
orthesteamhoseisttedorthe
Autoselect
TM
isturnedtoON
5. Check that the water tank is full. Note:
Whenrstlledorafterrunningdryitcan
take up to 45 seconds for steam to be
produced.
6. Check steps 1, then 2, then 3
The steam mop stops
producing steam
during use
7. Check steps 4, then 5, then 3
The steam mop is
producing too much
steam during use
8. Turn the Autoselect
TM
dial (2)
anti-clockwise to reduce the amount of
steam being produced
The steam mop is
producing too little
steam during use
9. Turn the Autoselect
TM
dial (2) clockwise to
increase the amount of steam being
produced
