Black & Decker Spacemaker Optima T1000 User Manual

remove the Mounting Template.
(Figure C)
4. Cover the counter top to catch
drilled wood chips.
CAUTION: Suitable eye
protection is recommended to
prevent injury from shavings
while using a drill.
5. Make a small starter hole by
hammering a nail or using a
smaller drill bit. Holding the drill
straight and vertical at the hole
marks, center and drill up
through the bottom of the
cabinet. (Figure D)
6. Insert a plastic washer on
each screw with the flat side of
the washer resting on the
cabinet bottom. Drop each screw
with the washer in place through
a drilled hole from inside the
cabinet. Repeat the procedure
with remaining screws and
washers. Thread a nut onto each
screw so that approximately 1/4”
of the screw is exposed beyond
the nut. (Figure E)
7. Slide the Mounting Bracket
above the nuts through the
U-shaped openings on the
Bracket. The Bracket will then be
resting on the nuts. (Figure F)
(See page 8).
7
Figure D
Figure E
Figure C
