5
SPACERS
SCREWS
WASHERS
MOUNTING
• Mounting Parts
(Part # SDC-MOUNTING KIT)
16 Spacers
4:
1
⁄2"
4:
1
⁄4"
4:
3
⁄16"
4:
1
⁄16"
12 Screws
4: 1"
4: 1
1
⁄2"
4: 2
1
⁄4"
4 Washers
• Mounting Template (in box)
You will also need:
• Tape
• Ruler
• Electric drill with a
1
⁄4” drill bit
and a
1
⁄32” drill bit
• Screwdriver
• Protective glasses
• A second person
Note: The use of all provided mounting hardware may not be necessary in the
installation of all Spacemaker
™
products.
Product may vary slightly from what is illustrated.
