Table 2-2 (continued). Rear-panel components and their functions.
Component Function
LED 11 Port 1 Unsecure Call Routing (SW 5)
*On = Unauthorized calls are routed to Port 1.
Off = Unauthorized calls are disconnected.
(Default)
Flash = Unsecure call is currently routed to Port
#1.
*Use this for an unsecured fax connection or to
monitor the number of unsecured modem call
attempts.
LED 12 Outbound Calls Enable/Disable (SW 3)
On = Outbound calls enabled. (Default)
Off = Outbound calls disabled.
Flash = Outbound call in progress.
LEDs 1–8 light when the corresponding port
number is selected as an outbound port.
