Chapter 2: Overview
1 2 3
Figure 2-35. Status LEDs on the fan tray.
Table 2-37. Status LEDs on the fan tray.
Number LED Status Description
1 Status 1 (green) On Operating condition
2 Status 2 (blue)
Off Operating condition
On Error indication
3 Hot swap (blue)
Off Hot swap option deactivated
On Hot swap option activated
