CHAPTER 5: Programming the ASD-4
Table 5-2: The ASD-4’s Custom Functions (Multi-Value Options)
1. Access the programming mode by pressing [#] [*] at a local phone or the Security
Access Code at a remote phone.
2. Change function settings by entering the function number, followed by a valid
entry from the settings available:
FUNCTION FACTORY OPTIONS
SETTING AVAILABLE
[2][1] Security Access Code [1] [2] [3] [4] any 1 to 4 digits
[2][2] FAX Access Code [1] [1] any 1 to 4 digits
[2][3] MODEM Access Code [2] [2] any 1 to 4 digits
[3][1] TAD and PHONE Ports’ [1] [0] OFF
Distinctive Ring [1] 1-burst ring
[2] 2-burst ring
[3] 3-burst ring
[3][2] FAX Port’s Distinctive Ring [2] [0] OFF
[1] 1-burst ring
[2] 2-burst ring
[3] 3-burst ring
[3][3] MODEM Port’s Distinctive Ring [3] [0] OFF
[1] 1-burst ring
[2] 2-burst ring
[3] 3-burst ring
[4][0] Rings to Answer Call [1] [1] to [9][9]
[4][1] Rings Available to [6] [0] to [9][9]
TAD and PHONE Ports
[4][2] Rings Available to FAX Port [3] [1] to [9][9]
[4][3] Rings Available to MODEM Port [3] [1] to [9][9]
[5] Phantom Ring Style [1] [1] to [7] (see Section
5.4.11)
[6] Automatic TAD-Transfer Timer [3][0] seconds [0] to [9][9] seconds
[7] RMN Phone Number none any phone number
up to 16 digits long
[8] RMN Conditions [1] [1] TAD
[2] FAX
[3] MODEM
[9][9][9]Reset to Factory Settings the values in
Tables 5-1 & 5-2
3. End your entry by pressing [*]. Make as many entries as you need.
4. Exit the programming mode by pressing [*] again.
