Chapter 2: Overview
2.4 Hardware Description
2.4.1 Local Extender
The Local Extender connects to the computer using the upstream USB Type A
connector.
1
2
Figure 2-1. Local extender.
Table 2-1. Local Extender components.
Number in
Figure 2-1
Type Description
1 Link port (RJ-45) Accepts RJ-45 connector for CAT5
(or better) cabling.
2 Device port (USB Type A) Used to connect the Local Extender unit
to the host computer.
