Hardened VDSL Ethernet Extender
Specifications
Applicable Standards IEEE802.3 10Base-T
IEEE802.3u 100Base-TX
Ethernet over VDSL
Fixed Ports 1 x 10/100Mbps Ethernet port with RJ-45 connector
1 x Ethernet over VDSL port with RJ-11 and Terminal
Block connectors
Speed
10Base-T
100Base-TX
Ethernet over VDSL
10/20Mbps for half/full-duplex
100/200Mbps for half/full-duplex
1, 3, 5, 10, 15, 20, 25, 30, 40, 50Mbps
Switching Method Store-and-Forward
Forwarding rate 14,880/148,810pps for 10/100Mbps
Cable
10Base-T
100Base-TX
Ethernet over VDSL
2-pair UTP/STP Cat. 3, 4, 5 up to 100m
2-pair UTP/STP Cat. 5 up to 100m
Cross-over telephone wires
LED Indicators Per Unit (3 LEDs)-
Power1, Power2, Power3
Per Port-
RJ-45 (2 LEDs): Link/ACT, FDX
RJ-11, Terminal Block (9 LEDs): Remote,
Local, Error, Link, 1, 2, 3, 4, 5
Dimensions 50mm (W) × 110mm (D) x 136mm (H)
(1.97” (W) x 4.33” (D) x 5.35” (H))
Weight 0.8Kg (1.76lbs.)
Power
Terminal Block: 12-30VDC
DC Jack: 12VDC, External AC/DC required
Operating Voltage &
Max.
Current Consumption
0.225A @ 12VDC, 0.113A @ 24VDC
Power Consumption 2.7W Max.
Operating Temperature -34°C ~ 74°C (-29°F ~ 165°F)
Storage Temperature -40°C ~ 85°C (-40°F ~ 185°F)
Humidity 10 ~ 95%, non-condensing
Safety UL60950, EN60950, IEC60950
Emissions FCC Part 15, Class A
CE: EN61000-6-2
EN61000-6-3
12
