MODELS:   
1
Griddle body (1 piece)
2
Griddle top and Hood (1 piece)
3
Stabilizing shelf (1 piece)
4
Left side shelf (1 piece)
5
Right side shelf (1 piece)
6
Front accessory shelf (1 piece)
7
Side handle
(1 piece)
8
Paper towel
holder (1 piece)
9
Bottle opener
(1 piece)
10
LPG hook
(1 piece)
11
LPG support
(1 piece)
12
Grease cup
(1 piece)
13
Caster wheels
(2 pieces)
14
Fixed wheels
(2 pieces)
15
Control knobs
(4 pieces)
16
Side shelf
bracket (L) (2 pieces)
17
Side shelf
bracket (R) (2 pieces)
18
Hood handle
(1 piece)
19
Hardware pack (1 piece)
a. Side shelf pegs (8 pieces)
b. Lock nuts (2 pieces)
c. M6x12 screws (15 pieces)
d. Small thumb screws (2 pieces)
e. Peg washers (8 pieces)
f. Large thumb screw (1 piece)
g. Medium thumb screw (1 piece)
h. M6 step bolts (8 pieces)
i. Shear pin (1 piece)
j. Cotter pin (1 piece)
k. Washers (2 pieces)
l. Acorn nuts (2 pieces)
m. Lock washers (2 pieces)
[a.] [c.] [h.]
[l.]
[m.]
[d.]
[e.]
[b.]
[f.] [i.] [j.]
[k.]
[g.]

