OWNER’S MANUAL | ASSEMBLY GUIDE MODEL:
ASSEMBLY GUIDE
{A1} Post 1 (1 piece) {A2} Post 2 (1 piece) {A3} Post 3 (1 piece) {A4} Post 4 (1 piece) {A5} Post 5 (1 piece) {A6} Post 6 (1 piece)
{A7} Post 7 (1 piece) {A8} Post 8 (1 piece) {A9} Post 9 (1 piece) {B} Foot base
(7 pieces)
{C} Foot cover
(14 pieces)
{D1} Cross beam
1 (1 piece)
{D2} Cross beam
2 (1 piece)
{D3} Cross beam
3 (1 piece)
{D4} Cross beam
4 (1 piece)
{D5} Cross beam 5
(4 pieces)
{D6} Cross beam 6
(2 pieces)
{D7} Cross beam
7 (1 piece)
{E1} Cross beam
connector 1 (1 piece)
{E2} Cross beam
connector 2 (1 piece)
{F1} Roof rib 1 (1 piece) {F2} Roof rib 2 (1 piece)
{F3} Roof rib 3 (1 piece)
{F4} Roof rib
4 (1 piece)
{G1} Support bracket
1 (1 piece)
{G2} Support bracket
2 (1 piece)
{G3} Support bracket
3 (1 piece)
{G4} Support bracket
4 (1 piece)
{H1} Roof top rib 1
(3 pieces)
{H2} Roof top rib 2
(3 pieces)
{J1} Side panel
1 (1 piece)
{J2} Side panel 2
(4 pieces)
{J3} Side panel 3
(2 pieces)
{K1} Shelf 1 (1 piece) {K2} Shelf 2 (1 piece) {K3} Shelf 3 (1 piece)
{K4} Shelf 4 (1 piece) {K5} Shelf 5 (1 piece) {L1} Shelf brace 1
(2 pieces)
{L2} Shelf brace 2
(2 pieces)
{L3} Shelf brace
3 (1 piece)
{M1} Roof panel
1 (1 piece)
PARTS LIST
