OWNER’S MANUAL | ASSEMBLY GUIDE MODEL: 6301
ASSEMBLY GUIDE
ExPLODED VIEW
1
Griddle body (1 piece)
2
Griddle top (1 piece)
3
Hood handle
(1 piece)
4
Mica washers
(2 pieces)
5
Hat channels
(2 pieces)
6
Grease cup
(1 piece)
7
Control knobs
(3 pieces)
8
PCB box
(1 piece)
9
Match holder
(1 piece)
10
Hose and
quick connect fitting
(1 piece)
11
Hardware pack (1 piece)
a. M6 shoulder bolts (4 pieces)
b. M5x10 screws (2 pieces)
c. M4x10 screws (4 pieces)
PARTS LIST
[a.] [b.]
[c.]
8
7 2
3
4
5
6
10
