OWNER’S MANUAL | ASSEMBLY GUIDE MODEL:
STEP 02
Place the oven base on its back. Remove the four (4) M8
flange nuts from the four (4) oven feet.
Use the four (4) M8 flange nuts to attach the heat shield and four (4)
oven feet to the bottom of the oven base.
STEP 03
Remove the eight (8) M6x12 screws from the oven body
side panels.
Use four (4) M6x12 screws to install one (1) side handle and two (2)
mica sheets to the oven body left side panel.
Repeat with the oven body right side panel.
STEP 04
Slide the square stone into the upper oven chamber
brackets.
Center the round stone on the floor of the oven chamber.
STEP 05
Remove the one (1) M5 screw from the door handle. Use
the one (1) M5 screw to attach the door handle to the front of the
oven door.
STEP 06
With the help of another person, set the pizza oven into
the oven base.
Note: Take extra care not to damage the burners. DO NOT let the
stones slide out.
To Next Page
