• power class: Class 3 (CDMA 800), Class 2 (CDMA 1900), Class 1
(DCS 1800, PCS 1900), Class 4 (GSM 850) as defined in GSM
5.05, Class 4 (GSM 900) as defined in GSM 02.06, Class E2 (GSM
850, GSM 900, DCS 1800, PCS 1900)
• transmitting frequency: Cell 824 to 849 MHz, GSM 880 to 915
MHz, DCS 1710 to 1785 MHz, PCS 1850 to 1910 MHz
• receiving frequency: Cell 869 to 894 MHz, GSM 925 to 960
MHz, DCS 1805 to 1880 MHz, PCS 1930 to 1990 MHz, A-GPS
E911: 1575 MHz
Wi-Fi network radio specifications:
• wireless LAN standard: IEEE 802.11b, IEEE 802.11g, IEEE
802.11n
• transmitting and receiving frequency: 2.412 to 2.472 GHz
Bluetooth radio specifications:
• single-band support: ISM 2.4 GHz
• transmitting and receiving frequency: 2402 to 2480 MHz
• Bluetooth Class 1
If your device supports NFC technology, the following specifications
apply:
• operating frequency: 13.56 MHz
• supported modes: reader/writer, card emulation, peer-to-peer
52
