Black+Decker BEBL7000 User Manual

ENGLISH
6
Switching On/Off (Fig. L)

WARNING: Use both hands to grip the product firmly
when switchingon.

CAUTION: Do not point unit discharge at self
orbystanders.

WARNING: Cut Hazard. When turning the tool off for
tube installation or any other reason, wait 10 seconds
for the fan to stop rotating beforedisassembly.
Your blower is fitted with a on/off switch located on the top
of the power head handle
4
.
• To switch the blower on, slide the on/off
2
switch
forward as shown in Fig.L.
• To switch the blower off, slide the on/off
2
switch back
as shown in Fig.L.
Fig. L
3
2
POWERBOOST FEATURE
The POWERBOOST feature is located on the powerhead. It
allows you to optimize the tool's performance and boost
the power asneeded.
• Switch the blowerON.
• To activate the “Boost” mode, slide the POWERBOOST
button
3
towards the auxillaryhandle.
• To deactivate the “Boost” mode, slide the POWERBOOST
button
3
away from the auxillaryhandle.
NOTE: Operate in “Normal” mode for most blowing needs.
Activate “Boost” mode as needed to clear or vacuum
heavydebris.
Cord Retainer (Fig. M)
• A cord retainer is incorporated into the rear of the
power head. It can be used in two different ways:
• To use the cord retainer as shown in Fig. M, hook the
extension cord under the retainer. Then plug the cord
from the power head into the extensioncord.
• To use the cord retainer as shown in Fig. M, loop the
extension cord over the power head cord and plug the
two ends into each other. Then hook the extension cord
under theretainer.
Fig. M
Use As A Blower (Fig. D, M, N)

WARNING: Ensure product is switched off and
disconnected from the powersupply.
• Fit fan cover
14
as shown in Fig. N until audible click
isheard.

CAUTION: CUT HAZARD. Ensure fan cover
14
is
securely seated and latched intoposition.
• Attach the blow tube assembly to the power head as
shown in Fig.D.
• Connect the cord on the power head to the power
supply (Fig. M).
• Hold the blow tube approximately 7 inches (180mm)
above the ground, turn the blower/vac on and using
a sweeping motion from side to side, advance slowly
keeping the accumulated debris/leaves in front of you
as shown in Fig.N.
Fig. N
• Once you have blown the debris/leaves into a pile, you
can convert to vacuum mode to collect thedebris.
• Using the air concentrator will help remove matted
debris andleaves.
USE AS A VACUUM
Vacuum Mode (Fig. F, I, J, Q, M, O)

WARNING: Ensure product is switched off and
disconnected from the powersupply.
To fit the leaf collection bag assembly to product:
• Remove blowtube.
• Push the flexible collection tube assembly onto the
power head until it is in the fully locked position and an
audible click is heard. (Fig. F).

WARNING: Do not operate blower without blow
tube or flexible collection tube securely in place.
Never reach down into housing through tubehole.
• Remove the fan cover
14
from the bottom of the
power head by inserting a screwdriver/hSex key in the
slot on the end of the fan cover (located on the back of
the power head), and removing the fan cover. (Fig. I)
• Attach the vacuum tube assembly to the power head
(Fig. J) by locating the assembly as indicated by arrow,
then pivot about this point until the locking/release
catch is fully engaged and an audible click is heard..

CAUTION: CUT HAZARD. Ensure the vacuum tube
assembly is securely seated and latched intoposition.
• Roll the open end of the bag and latch the retaining clip
17
closed. (Fig.Q)

Black+Decker BEBL7000 Specifications

General

Power Source	Corded Electric
Amperage	12 Amps
Air Volume	400 CFM
Mulching Ratio	16:1
Variable Speed	Yes
Functions	Blower, Vacuum, Mulcher
Air Speed	250 MPH
Type	Electric Leaf Blower & Vacuum
