5
ENGLISH
(Original instructions)
Children should be supervised to ensure that they do not
play with the appliance.
Residual risks.
Additional residual risks may arise when using the tool which
may not be included in the enclosed safety warnings. These
risks can arise from misuse, prolonged use etc.
Even with the application of the relevant safety regulations
and the implementation of safety devices, certain residual
risks can not be avoided. These include:
Injuries caused by touching any rotating/moving parts.
Injuries caused when changing any parts, blades or ac-
cessories.
Injuries caused by prolonged use of a tool. When using
any tool for prolonged periods ensure you take regular
breaks.
Impairment of hearing.
Health hazards caused by breathing dust developed when
using your tool (example:- working with wood, especially
oak, beech and MDF.)
Labels on tool
The following pictograms are shown on the tool along with the
date code:
Warning! To reduce the risk of injury, the user
must read the instruction manual.
Wear ear protectors with Impact drills. Exposure
to noise can cause hearing loss
Electrical safety
This tool is double insulated; therefore no earth
wire is required. Always check that the power
supply corresponds to the voltage on the rating
plate.
If the supply cord is damaged, it must be replaced by the
manufacturer or an authorised BLACK+DECKER Service
Centre in order to avoid a hazard.
Features
1. Variable speed switch
2. Lock on button
3. Forward/reverse switch
4. Drilling mode selector
5. Chuck
6. Side handle
7. Depth gauge (Not Supplied)
Assembly
Warning! Before assembly, make sure that the tool is
switched off and unplugged.
Turn the knob (6c) counter clockwise until you can slide
the side handle (6) onto the front of the tool as shown.
Rotate the side handle into the desired position ensuring
that the notches (6a) engage with the sprocket (6b).
Insert the depth guage (7) (Not Supplied) into the mount-
ing hole (7a).
Set the drilling depth as described below.
Tighten the side handle by turning the knob (6c)
clockwise.
Note:
depending on personal preference.
Fitting a drill bit
Open the chuck by turning the front part with one
hand while holding the rear part with the other.
the chuck.
Use
Warning! Let the tool work at its own pace. Do not overload.
Warning!
the location of wiring and pipes.
For drilling and for tightening screws, use forward
(clockwise) rotation. For loosening screws or removing a
jammed drill bit, use reverse (counter clockwise) rotation.
To select forward rotation, push the forward/reverse
switch (3) to the left position.
To select reverse rotation, push the forward/reverse
button to the right.
Warning! Never change the direction of rotation while the
motor is running.
Slacken the side handle (6) by turning the knob (6a)
counter clockwise.
Set the depth guage (7) (Not Supplied) to the desired
position. The maximum drilling depth is equal to the
distance between the tip of the drill bit and the front end of
the depth guage.
Tighten the side handle by turning the knob (6c)
clockwise.
For Impact drilling in masonry and concrete, set the
drilling mode selector (4) to the
position.
For drilling in steel, wood and plastics or for screw driving
set the operating mode selector (4) to the position.
