Black+Decker BES720 - Operations and Maintenance; Cross Cutting; Blade Jamming Handling

12
ENGLISH
(Original instructions)
uSwitch on the saw.
uPlace your hands (with ngers closed) at on the
workpiece and push the workpiece along and into the
blade (4).
uGuide at the side with your left or right hand (depending
on the position) only as far as the front edge of the saw
blade guard (2).
uAlways push the workpiece through to the end of the riving
knife (3) using the push stick (19) as shown in gure N.
uThe offcut piece remains on the saw table (1).
uSecure long workpiece against falling off at the end of the
cut ) with a roller stand etc.
Warning! Always use the push stick (19) when ripping small
workpieces.
Do not cut excessively small workpieces.
Cross Cutting
uLock the miter gauge (6) at 0 degree
uSet the bevel angle to 0 degree
uAdjust the saw blade (4) height
uHold the workpiece at on the table (1) and against the
fence. Keep the workpiece away from the blade.
uKeep both hands away from the path of the saw blade.
uSwitch the machine on and allow the saw blade to reach
full speed.
uHold the workpiece tightly against the fence and slowly
move the workpiece together with the fence assembly until
the workpiece comes underneath the upper blade guard.
uAllow the teeth to cut, and do not force the workpiece
through the saw blade. The saw blade speed should be
kept constant.
After completing the cut, switch the machine off, allow the saw
blade to stop and remove the workpiece.
Warning! Never push or hold the cut-off-side of the work-
piece.
Blade jamming handling
uEnsure the machine is disconnected from the power
source.
uRemove the workpiece. Be careful of your hands not
touching the saw blade.
uPress the overloaded protector (21) and connect the plug
again, the machine can resume working.
After use
u After use, wipe off chips and dust adhering to the tool with
a cloth or the like.
u Lubricate the sliding portions with machine oil to prevent
rust.
Protecting the environment
Z
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
household waste.
Products and batteries contain materials that can be
recovered or recycled reducing the demand for raw materials.
Please recycle electrical products and batteries according to
local provisions. Further information is available at
www.2helpU.com
Technical data
BES720 Type 1
Voltage V 230
Frequency Hz 50
Power input W 1800
No-load speed /min 5200
Blade diameter mm 254
Blade body thickness mm 2.0
Allowed range of kerf width mm 2.8
Bore size mm 30
Riving knife thickness mm 2.5
Max. cutting depth at 45º mm 58
Max. cutting depth at 90º mm 80
Blade bevel range 0 - 45º
weight kg 27.56
Level of sound pressure according to EN 62841:
L
pA
(sound pressure) 95 dB(A), Uncertainty (K) 3 dB(A)
L
WA
(sound power) 108 dB(A), Uncertainty (K) 3 dB(A)
EC declaration of conformity
MACHINERY DIRECTIVE
%
BES720 Table Saw
Black & Decker declares that these products described under
"technical data" are in compliance with:
EN62841-1:2015, EN62841-3-1:2014+A11:2017,
These products also comply with Directive
2006/42/EC, 2014/30/EU and 2011/65/EU.
For more information, please contact Black & Decker at the
following address or refer to the back of the manual.
