11
ENGLISH
(Original instructions)
Adjusting the depth of cut (fig. D)
The depth of cut should be set according to
the thickness of the workpiece. It should
exceed the thickness by approx. 2 mm.
• Loosen the knob (12) to unlock the saw
shoe.
• Move the saw shoe (8) into the desired
position. The corresponding depth of cut
can be read from the scale (11).
• Tighten the knob to lock the saw shoe in
place.
Adjusting the mitre angle (fig. E)
This tool can be set to mitre angles between
0° and 45°.
• Loosen the locking knob (6) to unlock
the saw shoe.
• Move the saw shoe (8) into the desired
position. The corresponding mitre angle
can be read from the scale (5).
• Tighten the locking knob to lock the saw
shoe in place.
Switching on and o
• To switch the tool on, move the lock-off
button (2) into the unlock position and
squeeze the on/off switch (1).
• To switch the tool off, release the on/off
switch.
Sawing
• Always hold the tool with both hands.
• Let the blade run freely for a few
seconds before starting the cut.
• Apply only a gentle pressure to the tool
while performing the cut.
• Work with the shoe pressed against the
workpiece.
Dust extraction (fig. F)
An adaptor is required to connect a vacuum
cleaner or dust extractor to the tool. The
adaptor can be purchased from your local
BLACK+DECKER retailer.
• Insert the dust extraction adaptor into
the saw dust outlet (13).
• Connect the vacuum cleaner hose to the
adaptor.
Hints for optimum use
• As some splintering along the line of cut
on the top side of the workpiece cannot
be avoided, cut on the side where
splintering is acceptable.
• Where splintering is to be minimised, e.g.
when cutting laminates, clamp a piece of
plywood onto the top of the workpiece.
Accessories
The performance of your tool depends on
the accessory used. BLACK+DECKER and
Piranha accessories are engineered to high
quality standards and designed to enhance
the performance of your tool. By using these
accessories you will get the very best from
your tool.
Maintenance
Your BLACK+DECKER tool has been
designed to operate over a long period of
time with a minimum of maintenance.
Continuous satisfactory operation depends
upon proper tool care and regular cleaning.
Warning! Before performing any
maintenance on the tool:
• Switch off and unplug the appliance/tool.
• Or switch off and remove the battery
from the appliance/ tool if the
appliance/tool has a separate battery
pack.
• Or run the battery down completely if it is
integral and then switch o.
• Unplug the charger before cleaning it.
Your charger does not require any
maintenance apart from regular cleaning.
• Regularly clean the ventilation slots in
your appliance/tool/ charger using a soft
brush or dry cloth.
• Regularly clean the motor housing using
a damp cloth. Do not use any abrasive or
solvent-based cleaner.
• Regularly open the chuck and tap it to
remove any dust from the interior (when
fitted).
