Black+Decker KA160 - Connecting a Vacuum Cleaner; Switching On and Off; Accessories; Maintenance

7
ENGLISH
(Original instructions)
u The polishing foam and pads (14) can be tted the same
way as the sanding sheets.
Tip of the sanding base (g. C)
When the sanding base tip (5) or tip holder (4) is worn, it can
be reversed or replaced. Spare parts are available from your
BLACK+DECKER dealer.
u Remove the screw (8).
u Reverse or replace the worn part.
u Fit and tighten the screw.
Finger attachment (g. D)
The nger attachment is used for ne detail sanding.
u Remove the screw (8).
u Remove the diamond-shaped tip holder (4) from the
sanding base.
u Fit the nger attachment (6) onto the sanding base.
u Fit and tighten the screw.
u Fit the appropiate sanding sheet (12) onto the nger
attachment.
Prole attachment (KA160K/KA161K only) (g. E)
The prole attachment is used for contour sanding.
u Remove the screw (8).
u Remove the diamond-shaped tip holder (4) from the
sanding base.
u Fit the prole attachment (7) onto the sanding base.
u Fit and tighten the screw.
Fitting and removing a sanding prole (g. F1 & F2)
u Choose the sanding prole most suitable for your
application.
u Place one end of the sanding prole (9) into the recess at
the front end of the prole holder (7).
u Push the other end of the sanding prole until it clicks into
place.
u To remove the sanding prole, push it forward and pull the
rear end out of the prole holder (g. F2).
Fitting a sanding sheet onto a sanding prole
(g. G)
u Align the sanding sheet (13) with the sanding prole (9).
u Press the sanding sheet onto the sanding prole, making
sure that the sanding sheet follows the shape of the
prole.
Assembly
Warning! Do not cover the ventilation slots when using the
tool. Hold the tool as shown in g. H. Make sure that the
sanding base is at on the workpiece.
Connecting a vacuum cleaner (g. I)
The tool has an adaptor to connect it to a vacuum cleaner
when sanding wood. To connect the tool to a vacuum cleaner,
proceed as follows:
Warning! Make sure that the tool is switched off and
unplugged.
u Fit the dust extraction connector (2) onto the adapter at
the back of the tool.
u Connect the hose of a suitable vacuum cleaner to the
connector.
Assembly
Warning! Let the tool work at its own pace. Do not overload.
Switching on and off (g. J)
Warning! Before connecting the tool to the power supply,
make sure it is switched off.
u To switch the tool on, press the part of the on/off switch (1)
marked 'I'.
u To switch the tool off, press the part of the on/off switch (1)
marked '0'.
Accessories
The performance of your tool depends on the accessory
used. and Piranha accessories are engineered to high quality
standards and designed to enhance the performance of your
tool. By using these accessories you will get the very best
from your tool.
Maintenance
Your tool has been designed to operate over a long period of
time with a minimum of maintenance. Continuous satisfactory
operation depends upon proper tool care and regular cleaning.
Warning! Before performing any maintenance, switch off and
unplug the tool.
u Regularly clean the ventilation slots in your tool using a
soft brush or dry cloth.
u Regularly clean the motor housing using a damp cloth. Do
not use any abrasive or solvent-based cleaner.
Mains plug replacement (U.K. & Ireland only)
If a new mains plug needs to be tted:
u Safely dispose of the old plug.
u Connect the brown lead to the live terminal in the
new plug.
u Connect the blue lead to the neutral terminal.
Warning! No connection is to be made to the earth terminal.
Follow the tting instructions supplied with good quality
plugs. Recommended fuse: 5 A.
