CF 300 – Flight Manual sect. 2 – Operating limitations
BY BLACKSHAPE
Document
n° BPU/FM003 Rev 3 dtd 03/06/2014 Page 21
-66
2.6. POWER PLANT INSTRUMENTS MARKINGS
The marks of the power plant and the meaning of the code of the colors are shown in the following
table:
INSTRUMENT
RED LINE
GREEN ARC
YELLOW
ARC
RED LINE
Min Limit.
Normal Op.
Range
Caution
Max Limit.
Tachometer
RPM
----------
1400-
5500
5500-
5800
5800
(5 min)
Oil temperature
°C
50 90-110
50-90
110-130
130
Head cylinder Temp.
°C
----------
75-135
----------
135
Oil pressure
bar
0.8 3.0 –
5.0
0.8 – 3.0
5.0 – 7.0
7.0
2.7. MISCELLANEOUS INSTRUMENTS MARKINGS
INSTRUMENT
RED LINE
GREEN ARC
YELLOW
ARC
RED LINE
Min Limit
.
Normale Op.
Range
Caution
Max Limit.
Voltmeter 10 Volt
12
–
14 Volt
----------
----------
2.8. WEIGHTS
· Maximum Take-Off Weight Kg. 472.5 Kg
· Maximum Baggage Weight See Weight & Balance section
WARNING
EXCEEDING WEIGHT LIMITATIONS MAY LEAD TO
OVERLOADING OF THE AIRPLANE AND CAUSE LOSS
OF CONTROL OF THE AIRPLANE AND/OR
STRUCTURAL DAMAGE.
