INSTALLATION
8 9
WATERFALL INSTALLATION
IMPORTANT
The outlet hose should be smooth bore (not corrugated) pipe installed over
as short a distance as possible with no kinks or bends.
We recommend that Blagdon smooth bore clear hose or Blagdon heavy duty
smooth bore black hose are used.
MAINTENANCE & CLEANING
The Blagdon Inpond All-in-One pump is centrifugal with a magnetic impeller
movement driven by a watertight synchronous motor. They require minimum
cleaning, only periodic cleaning of the impeller is necessary.
Routine Maintenance
Carry out routine maintenance when flow is visibly reduced.
1. Switch off electricity.
2. Remove filter from pond (do not use the cable to lift the pump.)
IMPORTANT - Failure to carry out routine maintenance leaving
the pump under reduced or no flow conditions for long periods
will result in a shorter pump life and will invalidate the
guarantee.
HOW IT WORKS - FLOW DETAIL
Flow control
Inlet grills
Coarse foam
Locking
handle
UVC contact chamber
Inlets
Ceramic biomedia
Polymer wool
pad cartridge
Medium foam
Low voltage
Pump
Automatic LED
spot light
12.5mm /
1
/
2
”
Photo Sensor
36
27
38
37
36
21
16
24
INSTALLING THE
WATERFALL OR FEATURE
Waterfall or
Feature
CONNECTING
OUTLET HOSES
The recommended hose size
for your Inpond filter is stated
in the filter performance and
specification chart.
Always secure hose with a
jubilee clip.
Warming the hose in a bucket of
boiling water can aid fitting.
Always ensure that the smaller
diameter hosetail is cut off and
removed to prevent reduced
filter performance.
Use the shortest possible hose
lengths to minimise flow
restrictions.
Avoid folds and kinks in the
hose, which will reduce flow and
filter performance.
