Blakeslee B-20 - Page 34

ITEMS # 5,6, & 7 NOT SHOWN
TYPE “A” BOWL GUARD ASSEMBLY
ITEM PART NO. DESCRIPTION QTY
1 74845 Cover Weldment 1
2 74048 Side Plate Weldment 1
3 74941 Handle 1
4 14849 Pin 1
5 08434 ¼-20 x 1” Screw 2
6 07282 ¼-20 Lock Nut 2
7 74955 Safety Switch Assembly 1
-33-
