21
EN
12/ CLEANING YOUR APPLIANCE
Fig. 15
The filtration system consists of several
elements:
--
The waste filter
--
The large main filter
--
The micro filter
The filters are located in the centre of the tub
and must be washed regularly to obtain opti-
mum washing results.
Actions :
➀➀
Before removing the filters, remove any
waste on the large main filter with a
sponge so that the waste does not block the
sprinkler arms. Rotate the spray arm as
shown in the drawing. (Fig. 14)
➁➁
Loosen the waste filter a quarter of a turn
and then remove it
③③
Remove the main filter
④④
Remove the micro filter
⑤⑤
Carefully clean filters
,
and
under running water (Fig. 15)
Re-installation:
Proceed in reverse order, inserting filters
and and then
Important :
Remember to lock the waste filter
in place by pushing it in fully and turning it a
quarter turn.
AA
AABB
CC
CCBBAA
CC
BB
AA
BB
CC
BB
AA
• CLEANING THE WASTE FILTERS
Fig. 14
AA
BB
CC
➁➁
③③
④④
⑤⑤
AA
CC
BB
➀➀
AA BB CC
