Operating manual BDC-22
15/17
GB
Tightness inspection
Hoses check
Make sure the connecting hoses (Fig. 12) are in a
good condition and correctly xed.
If the hoses are damaged, broken or badly connected
to the unions, they must be replaced.
When sticky materials are treated, check for possible
clogging along the hose, in the inlet and on the bae
plate inside the ltering chamber.
To clean, scrape the inlet (2, Fig. 12) from the outside
to remove deposits.
Hopper gasket check
Ensure that the Longopac
®
bag is tight with the gasket
(2, Fig. 13). The gasket must be replaced if it is torn,
cut, etc...
Clapet gasket check
Replace the gasket (1, Fig. 13) if it is not tight, or if it
is torn, cut, etc.
Disposing of the vacuum cleaner
Figure 14
Dispose of the vacuum cleaner in compliance with the
laws in force.
■ Proper disposal (electric and electronic
waste). (Applicable in the European Union
and in countries providing a separate
collection system)
The symbol (Fig. 14), which is present on the product
or in its documentation, indicates that the product
cannot be disposed of together with other domestic
waste at the end of its life cycle.
To prevent damage to the environment or health
caused by improper waste disposal, please separate
this product from other waste and recycle it
responsibly in order to support the sustainable
reutilisation of material resources.
This product cannot be disposed of together with
other commercial waste.
Wiring diagrams
Model (EU)
Figure 15
Item Type Description Q.ty
Q1 4083901850 Switch 2 pole 20A 1
Q2 4083901850 Switch 2 pole 20A 1
Model (US)
Figure 16
Item Type Description Q.ty
Q1 4083901814 Switch 2 pole 20A 1
Q2 4083901814 Switch 2 pole 20A 1
