Blastrac BDC-66 - Page 17

5
Fig. 01
Item
Part number
Description
Qty.
1
E09751
Filter house
1
2
E09772
Back legs bottom bracket
1
3
E09773
Back legs upper bracket
1
4
E09754
Handle
2
5
E07763
Divider
6
6
E03466
Rubber distance
3
7
E09755
Pulse tube
2
8
E09756
Top cover
1
9
E09778
Rubber impact plate
1
10
E09757
Filters secure plate
1
11
E09758
Filter bracket
3
12
E10600
Cartridge filter
6
13
E09874
Locking bar
3
14
BE0672
Eye bolt M10x120
3
15
E09759
Door filter house
1
16
E09685
Hose adapter 150-130
1
17
BE0560
M8 fork joint 8x16
2
18
BE0577
Turning knob M8x30
2
19
E11035
Logo
1
20
E09760
Compressor cover
1
21
E09791
Bracket
1
22
999-9155
Pipe clamp 25mm (set)
1
23
E09761
Compressor protection plate
1
24
E09598
Low friction wheel
2
25
E09597
Low friction castor wheel
2
26
E09762
Box
1
27
E09767
Pulse tube key
1
28
E06932
Drain box
1
29
E03197
KNEE 1/4'' MBSPT x 1/4'' FBSP
1
30
E14003
Mini ball valve 1/4" m/f bsp
1
31
E09768
Lifting beam
1
32
999-9106
Shock absorber A40-20
4
33
E01309
Adhesive rubber seal 40x20
2,9m
34
E00649
Adhesive rubber seal 25x5
3,5m
35
B21189
Adhesive rubber seal 20x10
2,7m
36
E11032
Distance plate
1
