Blastrac BDC-66 - Page 23

11
Fig. 04
Item
Part number
Description
Remarks
Qty.
1
E06989
Fan housing
1
2
E06954
Fan impeller type 1
1
3
E06965
Fan hub
1
4
E07059
Motor mounting bracket
1
5
E07594
BU fan unit (set)
1
6
E07067
Tension plate
1
7
E00620
Fan pulley
50Hz
1
E07278
Fan pulley
60Hz
1
8
E07278
Motor pulley
50Hz
1
E00620
Motor pulley
60Hz
1
9
E06131
V-belt
2
10
976657
Fan taperlock
1
11
222-2301-V
Motor taperlock
1
12
E07070
Belt guard
1
13
E07069
Fill up ring fan motor
1
14
E07580-IE3
Motor 5,5kW / 3000RPM
1
15
E03195
Ring fan
1
16
E09771
Distance plate
1
17
E09770
Silencer
1
18
E09769
Silencer top cover
1
19
BE0577
Turning knob M8x30
4
20
E00702
Fan adapter bearing house
1
21
E00705
Bearing
2
22
E07517
Fan shaft
1
23
E00951
Retaining ring
2
24
BE0256
Key
2
25
BE0076
Circlip for shaft
1
26
BE0327
M8 rubber washer
4
