Blastrac BDC-66 - Page 35

Page
BDC-66 UL
Ed.
6
PJ13.1140.03
HvdB +
Date
Date
Cable set
1
Modification
0 76
Appr
8 93
10
4
17-7-2014
8
2
=
Name
5
Blastrac bv
Customer:
Drawing number:
Page description:Project name:
© ART4 Technical Systems, Soest NL
17-7-2014
Last print
E09229
PE
850 mm
Ground Wire for connection to machine frame
AWG6 Green/yellow
Connect to inside cabinet wall
M6
M5 blue
M5 blue
M5 blue
M5 blue
M5 blue
TO FAN MOTOR
TERMINALS
200mm1850mm100mm
2150mm
X1.1
X1.2
X1.3
U
W
PE
V
CABINET
M5 blue
PE
Cable for fan motor
4xAWG12 Black Rubber (EPR)
COMPRESSOR
X1.4
X1.5
X1.6
Cable for compressor
4xAWG16 Black Rubber (EPR)
1
2
3
gn/ye
900mm
150mm 200mm
1250mm
CABINET
gn/ye
