Application
The BDC-99 is a very powerful mobile dust extractor. This high performance machine is exclusively designed
and built to be used in combination with Blastrac machines. It is equipped with 9 pieces of specially designed
high quality M-class cartridge filters.
The dust extractor is provided with an air pulse cleaning system which increases the life of the filter cartridges.
This system works by use of pressurized air, built up by a compressor. The air is led through a water separator
to the pulse system.
The conditioned air then passes a control valve which regulates the system pressure, and then builds up
pressure in the pulse tank. The pressurized air is used to generate a pulse of air which cleans the filters from
the inside. With every pulse of the pulse system, dust and particles are released from the filter surface.
Contact Blastrac B.V. for the correct execution and combinations.
1
Dust bin kit
6
Drain valve. Open regularly to
remove water from the air tank.
2
Longo pack kit
7
Pressure valve, must be set on 7 bar
3
Big bag kit
8
Water separator
4
Rubber impact plate
9
Air filters compressor
5
Manometer, shows the pressure of
the air tank. The pulse to clean the
filters must be given at 5 – 5.5 bar.
10
Lifting eye
