CONNECTIONS
Connections
A
C
D
E
F
G
H
B
I
J
SCART SCART input
HDMI 1 HDMI input
Video Component / Video input
YPbPr HD input (Ypbpr)
RF IN RF / TV Aerial Input
USB USB port
CI CARD IN Common Interface module
EARPHONE Earphone socket
A
I
B
J
C
D
E
F
G
H
R/L Audio shared for
Video/Composite and
component/ YPbPr
HDMI input with Audio
Return Channel
R/L
HDMI 2 (ARC)
VIDEO R
L
Y
Pb
Pr
US B
CI CARD IN
EARPHONE
