ACR 4231-034
10
Legend
1 On/off
Turn knob.
On
Off
Adjust volume:
Turn knob.
2
- Eject cassette tape
3 Cassette tape slot
4 FR (Fast Rewind):
Rewinds tape quickly to the beginning.
To switch off: press FF button.
5 PROG (Autoreverse)
To switch over to the other tape track -
press both buttons.
6 FF (Fast Forward)
Forwards tape quickly to the end.
To switch off: press FR button.
7 Display for
frequency range
frequency
memory bank
channel preset
track (cassette)
stereo
manual fine
tuning
sensitivity
(station search)
8
Station selection
automatic or manual (“m” in display).
Switch over by pressing lo • m 9
9 lo • m
Io lit up in the display indicates normal
sensitivity for the station search functi-
on.
Io not lit up in the display indicates high
sensitivity for the station search functi-
on.
m lit up indicates manual station fine
tuning.
Added feature:
Switch over from stereo to mono:
Press lo • m for longer than 2 seconds.
: M•L
AM and long-wave (LW) switch.
Press this button repeatedly if neces-
sary.
; 1- 5
For storing and recalling radio stations
< FM•T (frequency modulation)
Switch for the FM memory banks I, II,
III and “T” (Travelstore) - for storing and
recalling the six nearest, strongest stati-
on signals.
Store “T”:
Press FM•T until the search begins in
the display.
Recall “T”:
Press FM•T until T appears in the dis-
play. Then press the station button qui-
ckly and repeatedly if necessary.
= TREB (treble)
For adjusting the treble
> BASS
For adjusting the bass
