IMPORTANT SAFEGUARD
The instructions below will enable you to prepare your air
conditioner for operation as efficiently as possible.
Before use, make sure the air intake and outlet grilles are
unobstructed.
AIR-CONDITIONING WITHOUT INSTALLATION
Just a few simple steps and your comfort is ensured with
your appliance:
• Fit the air exhaust hose in the housing at the back of
the appliance (fig. A).
• Fit the window outlet to the end of the hose.
Place the air conditioner near a window or French
window.
Adjust the length of the hose to reach the window.
• Make sure the air exhaust hose is unobstructed.
• Open the window or French window slightly and
position the outlet (fig. B).
• If you have a sash window, place the bracket on the
window still, extend the bracket fully within the
window frame fix the bracket by using the pin, then
lower the window onto the bracket. Insert the
window outlet of the exhaust hose into the Slot, then
connect the hose to the air conditioner(fig. C).
• If you have a double window, use the sucker provided
to hold the two parts of the window together (fig. D).
Keep the air hose as short and free of curves as possible to avoid
bottlenecks.
