Horizontal Installation
0
l Confirm that Anti-Vibration
Anti-Vibration
Switches on both left and
@II
Switches
1111~
right sides are set to
position H.
l Attach bracket (L) and
bracket (R) using the
hexagonal bolts
(M5
x 8).
l Attach brackets (L) and (R)
to their respective
brackets
(5)
using tha
hexagonal bolts (M6 x 20)
and the hexagonal nuts
(M6).
where to attach the unit.
l Stick the supplied double-sided tape
to the bottom of the brackets (B) and
peel off the paper backing
l Affix the unit to the floor by pressing
in place.
take off the changer.
l Return the carpet to its original
position allowing the bolts to
protrude through.
to attach the changer on
top
of the
8
