EMA 455
Installation
Fig. 5a
Fig. 6
REMOTE SUPPLY
+
12V
GROUND
20A20A
FUSE
BRIDGE MODE
SPEAKERS
LR
FRONT
REAR
min. 4 Ohm
min. 4 Ohm
REMOTE SUPPLY
+
12V
GROUND
20A20A
FUSE
BRIDGE MODE
SPEAKERS
LR
FRONT
REAR
min. 2 x 2 Ohm
min. 2 x 2 Ohm
