GTb 200 A
26
Zatim regulatorom ltra 3 odaberite postavku ltra, ko-
jom se postiže dobar kontinuirani bas. Možda ćete morati
naizmjence optimirati postavku regulatora osjetljivosti 1
i postavku ltra 3.
Brujeći bas s prenaglašenim volumenom zahtijeva postavku
ltra s nižom frekvencijom.
Fazni regulator valja podesiti tako da se bas što bolje integrira
u sliku zvuka i da se ne čuje kao samostalni izvor.
Svoje postavke GTb 200 A provjeravajte i s do kraja okrenutim
regulatorom basa te eventualno uključenom Loudness (gla-
snoćom). Prejako pojačavanje subwoofera (poz.
1) dovodi
do isprekidane reprodukcije i može uništiti zvučnik.
Recikliranje i zbrinjavanje
Molimo Vas da za zbrinjavanja proizvoda koristite
sustave vraćanja i skupljanja koji vam stoje na ras-
polaganju.
Promjene pridržane!
USA
Please read these operating instructions before using
the equipment for the rst time.
Safety Notes
Please observe the following safety notes during the instal-
lation and connection.
Disconnect the negative terminal of the battery before
carrying out installation and connection work.
Observe the vehicle manufacturer's safety instructions
(regarding airbags, alarm systems, trip computers,
vehicle immobilisers).
When you drill holes, ensure that you do not damage any
vehicle components.
If the positive and negative cable are extended, ensure
that the cross section is not less than 2.5 mm
2
.
An incorrect installation can result in malfunctions of the
electronic vehicle systems or your car sound system.
Installation and connection instructions
With respect to accident safety, the GTb 200 A
must be secured in a professional way.
When selecting the installation location,
select a dry location that o ers su cient air
circulation for cooling the ampli er.
The GTb 200 A must not be installed on rear
shelves, rear seats or other locations that are
open to the front.
The installation location must be suitable to
accept the accompanying screws and pro-
vide a rm support (see page 28 / Fig. 1).
–
–
–
–
–
The ampli er power cable must be tted with a fuse no more
than 30 cm from the battery to protect the vehicle battery in
case of a short circuit between power ampli er and battery.
The fuse of the ampli er protects only the ampli er, not the
vehicle battery.
Switching on/o
One of the special features of the GTb 200 A is its automatic
switch-on.
The subwoofer box automatically switches on if a music
signal is received.
If there is no music signal for more than 60 seconds, the
GTb 200 A automatically switches o .
Connection (see page 29 / Fig. 2)
Connection 6 is connected to the positive pole of the
battery and connection 7 to negative vehicle ground. The
control of the GTb 200 A should ideally be a two-channel con-
trol, either via the preampli er outputs or the loudspeaker
outputs of the car sound system. A control solely via the right
or left channel is also possible since the low-frequency por-
tion of the music is generally identical on both channels.
The preampli er outputs are connected to the cinch (RCA)
sockets of the subwoofer box via a shielded sound cable.
With control via the loudspeaker outputs, the input connec-
tions of pos. 8/9 are fed to the closest loudspeaker cables
(front or rear) on the left and right. They are separated and
connected to the input connections. The polarity of the
+ or - connections must be observed. Bridge output stages
(BTL) can also be connected directly without an additional
adapter.
TIM function:
For car sound systems with activated TIM function, the
GTb 200 A must be controlled via the loudspeaker outputs
of the car sound system and not via the RCA inputs (see
page 29 / Fig. 2 of the operating instructions).
1 Input sensitivity
2 Phase position
3 Upper cut-o frequency
4 Connector cable
5 Preampli er inputs
6 + Battery
7 - Ground
8 Left loudspeaker input
9 Right loudspeaker input
: 10 A fuse
; Status display (Protect/Power)
Settings
The following control setting is recommended as basic set-
ting before putting the device into operation: Sensitivity
(gain) Pos. 1 to minimum, phase Pos. 2 to 0°, lter (cross-
over) Pos. 3 to approx. 80 Hz. Switch on the device and
select a musical piece with distinctive bass playback.
GTb_200_A_22LG.indd 26GTb_200_A_22LG.indd 26 21.10.2010 14:16:30 Uhr21.10.2010 14:16:30 Uhr
