BM40/2 JOYSTICK MONOBLOCK DIRECTIONAL CONTROL VALVE / INSTRUCTIONS MANUAL
5
EN
Drawing 2
JOYSTICK PARTS
Nº Parts Parts Nº sub part Sub part
4 Joystick kit
4.1 Plate
4.2 Bolts
4.3 Spool End
4.4 Spool End
4.5 Pin
4.6 Pin
4.7 Seeger
4.8 Nut
4.9 Junctions
4.10 Square Plate
4.11 Srew
4.12 Handle End
4.13 Bellow
4.1
4.2
4.3
4.4
4.5
4.6
4.7
4.7
4.8
4.9
4.10
4.11
4.12
4.0
4.6
