BLEASE QUALITY DOCUMENT
BQD 084.V2
10/5/96
Page 1 of 3
Checklist and Calibration Record for 8500 Anaesthesia Ventilator
Front Panel Part Numbers: Issue: 4 Software
version:
BAV
Serial No: Document No: 129TC000 Supply Gas: Fresh Gas:
Works Order No: Date: Signature:
Ref Description Value Units Notes
5.2 Initial Inspect, mains in locked-plug type, finger proof
exhaust, gas inlet, orientation
Gas Inlet Fixing =
Inlet (USA O
2
green, USA Air yellow,
UK 0
2
White, UK Air White/Black) Inlet ID =
Bellows =
P/F
USA/UK
USA/UK
Ad/Paed
P/F
⇒
Colour
Ad/Paed
USA/UK
5.3 Leakage/Continuity mains supply volts
Mains insulation (500v dc)
Earth Continuity
Earth equipot Continuity (≤ 0.2R)
Earth Leakage Normal (≤ 500µA)
Reverse (≤ 500µA)
Supply (sfc) Normal (≤ 1000µA)
Reverse (≤ 1000µA)
-------------
-------------
-------------
-------------
-------------
-------------
-------------
-------------
Vac
Mohm
Ohms
Ohms
µA
µA
µA
µA
5.4 Fresh Gas Leak Test
Fresh gas alarm, Tv 0.5 Lpm
Fresh gas alarm, Tv 0.25 Lpm
P/F
P/F
P/F
P/F
P/F
P/F
5.5 Printer Out, Pressure high/low lim = 20 & prod model,
Batch no., manu/cal date, soft vers, cal gas, option defaults,
pressure zero ±0.1, flow zero ±0.5, Lims ±1.
8500 pressure low alarm delay 20 seconds
P/F P/F
5.6 Battery Backup
Vent/mains off, vent on → mains fail
Mains on, vent → normal operation
Mains off, battery charge off, mains fail on
1 min mains fail warning
mains on, battery charge on, mains fail off
P/F P/F
5.7 Compliance Test
Absorber Switching connection
P/F
P/F
P/F
P/F
5.8 Mute Timeout Delay (seconds)
120
-------------
-------------
----------- -----------
secs
5.9 Supply Gas Low alarm On (Standby)
Low alarm Off (Standby)
-------------
-------------
psi
psi
Checked:-_______
