Operating Instructions for Suspended Jacks
2
Concerning these operating instructions
These operating instructions apply to several series with three different construction methods:
Hydraulic (-pneumatic) construction
Pneumatic construction
Electrohydraulic construction
• Pictures or text sections marked with the symbols shown above only apply to the jacks of the respective construction.
• Position numbers [1] in the operating instructions always refer to the pictures shown here and the component
overview.
• Cross-references () must be taken into consideration.
Overview of the Series
The overview shows a variant of each series.
Component overview for all series
[1]
Tilt protection bar
[2]
Control elements
[3]
Drain valve
[10]
[4]
Manual pump
[9]
[5]
Oil drain plug load stroke
[8]
[7]
[1]
[6]
Compressed air supply
[2]
[7]
Oil dipstick load stroke
[3]
[8]
Oil drain plug retrieval
[11]
[4]
[9]
Oil dipstick retrieval
[10]
Piston rod
[5]
[11]
Cover
