Blitz GHUSE Series - Transport, Installation, and Assembly; Preparing the Lifting Cylinder

Operating Instructions for Suspended Jacks
8
4 Transport, Installation and Assembly
DANGER
Risk of death and severe injury from improper transport
 Always transport the lift table with suitable hoisting and transport devices (e.g. forklift or crane).
 Never stay under suspended loads.
Safety notes
 Hoist the jack at viable spots only.
 Move the lifting cylinder horizontally and with the operating elements at the top.
 Secure moving and loose parts.
4.1 Make the Lifting Cylinder ready for Operation
 Note variants of the hydraulic construction.
Without operating elements With operating elements
A
A
C
B
 Remove cap A.
In addition, replace cap B with the supplied
ventilation screw.
 Remove cap A.

For jacks with retrieval, connect hose C.
D
D
 Replace cap D with the supplied ventilation screw.
H
H
H
E
