The Puck Q12A / Q12W Manual Rev. B Copyright (c) 2011-12 Blizzard Lighting, LLC
2. MEET THE PUCK™ Q12A / Q12W FLAT LED PAR
CAN
CONTROL FEATURES
•RGBAcolormixingvia12x10-WattQuadColorRGBALEDs(Q12A)
•RGBWcolormixingvia12x10-WattQuadColorRGBWLEDs(Q12W)
•Variableelectronicstrobe
•Variableelectronicdimmer
•Built-inautomatedprogramsviaDMXandmaster/slave
•Built-insoundactiveprograms
•FullRGBA/RGBWcolormixinginstandaloneandmaster/slave
•RGBA/RGBW(4-Channel)andextended(7-Channel)DMXmodes
ADDITIONAL FEATURES
•LightweightandCompact(ItkeptitsNewYears’resolution!)
•4-ButtonLEDcontrolpanelforeasyprogramming
•Lightsource:12x10-WattLEDs,Quad-Color
•Dualbracketforexibilityinmounting
•Poweroutletforxturelinking(upto10xturesor3amps)
•wiCICLE
®
Enabled functionality allows plug-and-play operation with
our wiCICLE
®
Brand Wireless DMX system
DMX Quick Reference (7-Channel Mode)
Channel What It Does
1 Dimmer
2 Red Intensity
3 Green Intensity
4 Blue Intensity
5 Amber / White Intensity
6 Strobe (0-15 off, 16-255 strobe
slow <-> fast)
7 Color Macros (slow <-> fast)
DMX Quick Reference (4-Channel Mode)
Channel What It Does
1 Red Intensity
2 Green Intensity
3 Blue Intensity
4 Amber / White Intensity
