MAKING THE CONNECTIONS
P18
SPEAKER CONNECTIONS
AUDIO RECORDER
CASSETTE DECK
OTHER AUDIO SOURCE
TUNER
CD PLAYER
TURNTABLE
CONTROL
P
t
r
c
e
e
s
l
s
e
t
s
o
R 100
AM/FM RD S PLL Tuner
TV
Pr o t e c t !
If the speaker cable is shorted during working, V 100
will automatically come to protection mode, and VFD
will display " Protect ! ". Now you need to turn off
V 100, check the speaker cable, and make sure all
speaker cable is connected correctly, then turn on
V 100 again. V 100 will return to normal working mode.
-
+
-
+
