Blomberg DWT37300 - Preparation for Installing Mounting Brackets; Adjusting Height

7
USA
6.2 PREPARATION FOR INSTALLING MOUNTING BRACKETS
B
B
A
A
WARNING
Dishwasher must be secured to adjacent
cabinetry using the mounting brackets
provided. Failure to do this may cause
damage to property or bodily injury.
Place the two mounting brackets into the top
corners of the dishwasher.
Fix the mounting brackets (A) to the top
corners of the dishwasher, with the screws
supplied.
Bend sides of mounting brackets (B) in order to
fix from sides (if necessary).
(861
mm - 911mm)
33
7
/
8
- 35
7
/
8

1
15
/
16

(50mm)
6.3 ADJUSTING HEIGHT
If the height of the enclosure is 337/8” to 357/8” (861 mm - 911mm) adjust supports as
shown in the figure.
Supplied (4)
