Tumble Dryer Service Handbook
4
1.7.2. Insulation : TS 9760 H05V2V2-F 3G1,5mm
2
1.7.3. Plug : Earthed ,PVC injected
1.7.4. Length (mm) : 1605
1.8. Motor
1.8.1. Type : 2 – phase asenkron
1.8.2. Power (W) : max 250
1.8.3. Main Winding (ohm) : 19,5± 5%
1.8.4. Auxillary Winding(ohm) : 19,5± 5%
1.8.5. Motor speed (7 kg (rpm)) : 2750
1.8.6. Drum speed (rpm) : 52 ± 2
1.8.7. Insulation : Sınıfı : F
1.8.8. Run capacitor : 9 mF ± %5
1.9. Heater
1.9.1. Type : Open wire spiral heating element
1.9.2. Nominal Power&Voltage(W) : 230Vac, 1600+900 = 2500 ± %5
1.9.3. Resistance(ohm) : 1600 W 1. level power (57.63 ohm± %5)
: 900 W 2. level power (32.41ohm± %5)
Warning: NTC (regulating thermistor) is damaged, change the heating element
completely. Also check whether the motor or the fan is blocked or the belt is broken.
1.9.4. Manual resetting thermostat : 160°C ±3°C
Rating : 250Vac – 16A
Type : ELTH 261PB
NOTE: If the heater does not work because of manuel resetting thermostat is open curcuit, do
not change heater with the new one. You should do the following operation that described
below.
