Tumble Dryer Service Handbook
3
1 Technical Specification:
1.1. Product Definition
1.1.1. Manufacturer : Arçelik A.Ş.
Cerkezkoy - Tekirdag / TÜRKĐYE
1.1.2 Model : TKF 8439/8439 A / 8439S
1.1.3 Capacity (kg) : 8
1.1.4 Programs (Qty) : 14 sensor contolled program
1 time program
1 ventilation program
(heater off)
1.2. Dimensions
1.2.1. Height (mm) : 846
1.2.2. Depth (mm) : 598
1.2.3. Width (mm) :595
1.3. Package
1.3.1. Material : PE bag (Shrink-pack)
1.3.2. Supporter : Polystrofoam / Wood
1.3.3. Dimensions :
Height (mm) : 880
Depth (mm) : 660
Width (mm) : 650
1.4. Weight
1.4.1. Unpacked (kg) : 38
1.4.2. Packed (kg) : 40
1.5. Working Condition
1.5.1. Temperautre :
Min. room temperature : 5° C
Max. room temperature : 35° C
1.5.2. Humudity : %95 RH
1.6. Electrical Specification
1.6.1. Voltage (V / Hz) : 220-230 V / 50 Hz
1.6.2. Power (kW) : 2,7 kW
1.6.3. Current (A) : 12
1.7. Power Cord
1.7.1. Type : 3 x 1.5 mm2 Cord Copper wire
