Tumble Dryer Service Handbook
6
1.9.5. NTC (regulating thermistor) : 19.500 ohm @ 25°C
Type : ELTH 279
1.10. Door NTC
Door NTC (ohm) : 12.000 ohm @ 25°C
1.11. Body :
1.11.1. Material : Sheet metal
1.11.2. Finish : Acyrlic powder paint
1.12. Drum :
1.12.1. Material : Aluzinc/Stainles steel
1.12.2. Volume ( lt ) : 118
1.12.3. Drum speed( rpm ) : 54±2
1.12.4. Front door opening (mm) : 395x320
1.12.5. Proces air flow (m
3
/h) :190
1.12.6. Maximum loading Capacity:
Cotton(kg) : 8
Delicate, Synthetic (kg) : 4
1.13. Control System Specifications :
1.13.1. On/off Button : 250 V, 16 (4)A
1.13.2. Door Switch : 250 V, 3 (1)A veya 16(4)A
1.13.3. Suppression Fiter : C907C21 0,15 uF(X1) + 1Mohm +
2x0.027uF(Y2)
1.13.4. Program Timer : Elektronic Control Card
220 -240V , 50 Hz
1.14. Pump
1.14.1. Number of turns:2x3250
1.14.2. Wire diameter:0,1 mm
1.14.3. Resistance:956 Ω± %8
1.14.4. PCT C870 Epcos
1.14.5. PA6/66 Grilon TS V0,UL 94V-0,GW-650°C
1.14.6. PA6 Latamid 6H V0, UL 94V-0, GW-650°C
