Arçelik/Blomberg 2009 ARES MLCD
8
kg
Tumble Dryer Service Handbook
9
Motor:
Tumble and fan turns via 2 poles asenkron motor. Motor turns 2750 prm ans has a 9 uF
capacitor. Asenkron motor is controled by two Control panel two relays one of them for
direction, other one is for energy that placed in control.
Auxiliary
Winding
Common
Run
Capasitor
Auxiliary
Winding
Main
Winding
Common
Main Winding
