Blue Bird BB550A - Steering

28
STEERING
ITEM PART NO. QTY. DESCRIPTION
1 ........ 109740........1........ ARM WELDMENT, RIGHT
2 ........ 109525........1........ STEERING ROD
3 ........ 990517........2........ WASHER, 3/8
4 ........ 990037........2........ PIN, COTTER, 3/32 X 3/4
5 ........ 109742........1........ ARM WELDMENT, LEFT
6 ........ 990654........2........ COTTER PIN, 5/32 X 1 1/4
7 ........ 109333........2........ WASHER, 3/4, SAE
8 ........ 102454........2........ E-RING, 3/4”
9 ........ 104556........ 2 ........ WHEEL ASSEMBLY
10 ...... 101905........1........ TIRE
11 ...... 104618........1........ RIM
12 ...... 912234........1........ AIR VALVE
13 ...... 923557........1........ ENDCAP
14 ...... 977356........1........ NOTCHED ENDCAP
.......... 977353........2........ ROLLER BEARING (NOT SHOWN)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
8
3
4
6
7
