Blue Clean 7830 - Page 8

AR BLUE CLEAN 7830 - 7850 - 7870
USE AND MAINTENANCE HANDBOOK page 8
Connect the water supply hose D to the infeed fitting E (see fig. 5). It is recommended
to use a reinforced hose having an inner diameter of at least 10 mm. The water intake
must be of at least 15 l/min and have a max inlet temperature of 60 °C.
Fig.5
Fill the fuel tank F (see fig. 6) with gasoil (Diesel).
Fill the detergent tank G (see fig. 6) with a biodegradable product.
Fig.6
Make sure that the electrical tension and amperage are suitable for the machine. The
cleaner must be connected to a suitable feeding point equipped with an efficient
contact to earth and controlled by an overload cut out switch.
The detergent is applied by opening the intake device of the lance
(on the position - see figure) and then operating with the gun
lever.
D
E
F
G
